CAD32M7 – Schneider Electric TeSys D control relay – 3 NO + 2 NC – <= 690 V - 220 V AC standard coil — SCHNEIDER

Product image for reference. Check the manufacturer's documentation for exact appearance and dimensions.

SCHNEIDER

CAD32M7 – Schneider Electric TeSys D control relay – 3 NO + 2 NC – <= 690 V - 220 V AC standard coil

Brand
SCHNEIDER
Model / part no.
CAD32M7
Category
Switches & Relays
Type
Control Relays & Sockets
In stock. Price on request. Our team confirms price and quantity with every quotation.
Request a Quote

TeSys D control relay, 5 contacts (3NO + 2NC), 10A/690V, for control of electromagnetic loads AC-15/DC-13. It provides a 220V 50/60Hz AC control circuit, connection by screw clamp terminals. For high operating rates until 180 cycles/min and ambient temperature -40/+60°C, it procures high reliability and durability. Compact (45mm width), for clipping on 35mm DIN rail or fixing by screw. Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine), Green Premium product (RoHS/REACh).

Specifications Source: Schneider Electric product page
Product or component typeControl relay
Device short nameCAD
Contactor applicationControl circuit
Utilisation category
  • DC-13
  • AC-14
  • AC-15
Pole contact composition3 NO + 2 NC
[Ue] rated operational voltage<= 690 V AC 25...400 Hz
Control circuit typeAC at 50/60 Hz
[Uc] control circuit voltage220 V AC 50/60 Hz
[Uimp] rated impulse withstand voltage6 kV conforming to IEC 60947
[Ith] conventional free air thermal current10 A (at 60 °C)
Irms rated making capacity
  • 140 A AC conforming to IEC 60947-5-1
  • 250 A DC conforming to IEC 60947-5-1
[Icw] rated short-time withstand current
  • 100 A - 1 s
  • 120 A - 500 ms
  • 140 A - 100 ms
Associated fuse rating10 A gG conforming to IEC 60947-5-1
[Ui] rated insulation voltage
  • 600 V UL certified
  • 600 V CSA certified
  • 690 V conforming to IEC 60947-5-1
Mounting support
  • Plate
  • Rail
Connections - terminals
  • Screw clamp terminals 1 cable(s) 1…4 mm²flexible without cable end
  • Screw clamp terminals 2 cable(s) 1…4 mm²flexible without cable end
  • Screw clamp terminals 1 cable(s) 1…4 mm²flexible with cable end
  • Screw clamp terminals 2 cable(s) 1…2.5 mm²flexible with cable end
  • Screw clamp terminals 1 cable(s) 1…4 mm²solid without cable end
  • Screw clamp terminals 2 cable(s) 1…4 mm²solid without cable end
Tightening torque
  • 1.7 N.m - on screw clamp terminals - with screwdriver Philips No 2
  • 1.7 N.m - on screw clamp terminals - with screwdriver flat Ø 6 mm
  • 1.7 N.m - on screw clamp terminals - with screwdriver pozidriv No 2
Control circuit voltage limits
  • 0.3...0.6 Uc (-40…70 °C):drop-out AC 50/60 Hz
  • 0.8...1.1 Uc (-40…60 °C):operational AC 50 Hz
  • 0.85...1.1 Uc (-40…60 °C):operational AC 60 Hz
  • 1...1.1 Uc (60…70 °C):operational AC 50/60 Hz
Operating time
  • 12...22 ms coil energisation and NO closing
  • 4...12 ms coil de-energisation and NO opening
  • 4...19 ms coil energisation and NC opening
  • 6...17 ms coil de-energisation and NC closing
Mechanical durability30 Mcycles
Maximum operating rate180 cyc/mn
Inrush power in VA70 VA 50 Hz (at 20 °C)
Hold-in power consumption in VA8 VA 50 Hz (at 20 °C)
Minimum switching voltage17 V
Minimum switching current5 mA
Non-overlap time
  • 1.5 ms on energisation between NC and NO contact
  • 1.5 ms on de-energisation between NC and NO contact
Insulation resistance> 10 MOhm
Mechanical robustness
  • Shocks control relay open: 10 Gn for 11 ms conforming to IEC 60068-2-27
  • Shocks control relay closed: 15 Gn for 11 ms conforming to IEC 60068-2-27
  • Vibrations control relay open: 2 Gn, 5...300 Hz conforming to IEC 60068-2-6
  • Vibrations control relay closed: 4 Gn, 5...300 Hz conforming to IEC 60068-2-6
Height77 mm
Width45 mm
