LADN40 – Schneider Electric Auxiliary contact block, TeSys D, 4NO, front mounting, screw clamp terminals — SCHNEIDER

Product image for reference. Check the manufacturer's documentation for exact appearance and dimensions.

SCHNEIDER

LADN40 – Schneider Electric Auxiliary contact block, TeSys D, 4NO, front mounting, screw clamp terminals

Brand
SCHNEIDER
Model / part no.
LADN40
Category
Contactors
Type
Auxiliary Contacts & Blocks
In stock. Price on request. Our team confirms price and quantity with every quotation.
Request a Quote

TeSys D instantaneous auxiliary contact block, for contactors LC1D, LC1F and control relays CAD. It provides 4NO contacts rated up to 10A/690V AC, connection by screw clamp terminals. Clip-on front mounting, it procures high reliability and durability. Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHS/REACh).

Specifications Source: Schneider Electric product page
Product or component typeAuxiliary contact block
Device short nameLADN
Range compatibility
  • TeSys D CAD
  • TeSys D LC1D
  • TeSys F LC1F
  • TeSys F CR1F
  • TeSys Deca CAD
  • TeSys Deca LC1D
Mounting locationFront
Pole contact composition4 NO
Contacts operationInstantaneous
[Ue] rated operational voltage690 V AC 25...400 Hz
[Ie] rated operational current
  • 6 A at 120 V AC-15
  • 1.04 A at 690 V AC-15
  • 0.55 A at 125 V DC-13
  • 0.1 A at 600 V DC-13
[Ui] rated insulation voltage
  • 690 V conforming to IEC 60947-5-1
  • 600 V conforming to UL
  • 600 V conforming to CSA
[Ith] conventional free air thermal current10 A (at 60 °C)
Standards
  • EN/IEC 60947-5-1
  • GB/T 14048.5
  • EN 50012
  • UL 60947-5-1
  • CSA C22.2 No 60947-5-1
  • IEC 60335-1:Clause 30.2
  • IEC 60335-2-40:Annex JJ
  • UL 60335-2-40:Annex JJ
Product certifications
  • CB Scheme
  • UL
  • CSA
  • CCC
  • EAC
  • UKCA
Irms rated making capacity
  • 140 A AC conforming to IEC 60947-5-1
  • 250 A DC conforming to IEC 60947-5-1
Permissible short-time rating
  • 100 A 60 °C 1 s
  • 120 A 60 °C 500 ms
  • 140 A 60 °C 100 ms
Protection typeGG fuse 10 A
Mechanical durability30 Mcycles
Minimum switching current5 mA
Minimum switching voltage17 V
Non-overlap time
  • 1.5 ms on de-energisation no overlap between NC and NO contact
  • 1.5 ms on energisation no overlap between NC and NO contact
Insulation resistance> 10 MOhm
Connections - terminals
  • Screw clamp terminals 1 cable(s) 1…4 mm²flexible with cable end
  • Screw clamp terminals 1 cable(s) 1…4 mm²flexible without cable end
  • Screw clamp terminals 2 cable(s) 1…2.5 mm²flexible with cable end
  • Screw clamp terminals 2 cable(s) 1…4 mm²flexible without cable end
  • Screw clamp terminals 1 cable(s) 1…4 mm²rigid without cable end
  • Screw clamp terminals 2 cable(s) 1…4 mm²rigid without cable end
Tightening torque
  • 1.7 N.m - with screwdriver flat Ø 6 mm
  • 1.7 N.m - with screwdriver Philips No 2
  • 1.7 N.m - with screwdriver pozidriv No 2
Height48 mm
Width44 mm
Depth42 mm
Net weight0.05 kg
ColourDark grey
Environmental characteristicNormal environment
IP degree of protectionIP2X conforming to IEC 60529
Protective treatmentTH conforming to IEC 60068
